TEMPO FI-100 Fiber Identifier – Live Fiber Detector for Singlemode & Multimode Optical Cables
TEMPO FI-100 Fiber Identifier – Live Fiber Detector for Singlemode & Multimode Optical Cables
السعر العادي
950,000 IQD
سعر البيع
950,000 IQD
السعر العادي
يتم احتساب الشحن عند إتمام الشراء.
متوفر في المخزون
The TEMPO FI-100 Fiber Identifier is a professional, non-intrusive testing tool designed to detect live optical fibers without disconnecting them. It supports both singlemode and multimode fibers and allows technicians to identify active signals, signal direction, and relative power levels.
| Brand | TEMPO |
|---|---|
| Model | FI-100 |
| Product Type | Fiber Identifier |
| Fiber Type | Singlemode & Multimode |
| Supported Wavelength Range | 800 – 1700 nm |
| Identified Signal Types | 270 Hz, 330 Hz, 1 kHz, 2 kHz |
| Detector Type | InGaAs |
| Adapter Sizes | 250 µm / Ribbon, 900 µm, 2 mm, 3 mm |
| Signal Direction | Left & Right LED Indicators |
| Signal Direction Test Range | -46 to +10 dBm (1310 nm) |
| Signal Power Test Range | -50 to +10 dBm (1550 nm) |
| Insertion Loss (Typical) | 0.3 dB @ 1310 nm / 1.5 dB @ 1550 nm |
| Insertion Loss (Maximum) | 0.8 dB @ 1310 nm / 2.5 dB @ 1550 nm |
| Power Supply | 2 × AAA Alkaline Batteries |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Dimensions | 196 × 30.5 × 27 mm |
| Weight | 195 g |
| Certifications | CE, FCC, WEEE |
| Application | Fiber Installation, Maintenance, Live Fiber Identification, Network Troubleshooting |
