The CMX A8 is an 8-channel, on-wall music amplifier with an 8″ touch screen and built-in Wi-Fi, Bluetooth, USB/TF and FM playback—made for simple multi-room background audio with per-channel level control in a compact form factor.
-
8×30W amplification for up to eight speakers—clean power with easy touch control.
-
Multiple sources: Wi-Fi streaming, Bluetooth, USB, TF/microSD and FM radio.
-
Independent channel volumes so each of the 8 channels can be adjusted separately.
-
Everyday performance: 20 Hz–20 kHz response; Wi-Fi range ≤30 m, Bluetooth ≤10 m.
-
Compact wall unit: only 186.5 × 122 × 48.8 mm for clean, in-room installs.
Technical Specifications
| Parameter |
Value |
| Brand / Model |
CMX Audio / A8 |
| Type |
8″ touch-screen on-wall amplifier |
| Output Power |
8 × 30 W |
| Channels |
8 (independent volume control) |
| Audio Sources |
Wi-Fi, Bluetooth, USB, TF/microSD, FM |
| Extended Memory |
TF/microSD up to 64 GB |
| Frequency Response |
20 Hz – 20 kHz (±3 dB) |
| Wireless Range |
Wi-Fi ≤ 30 m; Bluetooth ≤ 10 m |
| Product Size (W × H × D) |
186.5 × 122 × 48.8 mm |
