ATLANTIC ATPDU-CF24 Smart PDU – 32A 3-Phase, 32 Outlets, Metered PDU with LCD, SNMP, Modbus, IEC C13/C19
ATLANTIC ATPDU-CF24 Smart PDU – 32A 3-Phase, 32 Outlets, Metered PDU with LCD, SNMP, Modbus, IEC C13/C19
السعر العادي
350,000 IQD
سعر البيع
350,000 IQD
السعر العادي
يتم احتساب الشحن عند إتمام الشراء.
متوفر في المخزون
The ATLANTIC ATPDU-CF24 is a three-phase smart metered PDU designed for data centers and enterprise IT environments. It provides accurate power monitoring, network management, and environmental sensor support with a clear LCD display.
| Brand | ATLANTIC |
|---|---|
| Model | ATPDU-CF24 |
| Product Type | Smart Metered PDU |
| Electrical Measurement | Current, Voltage, Frequency, Active Power, Apparent Power, Reactive Power, Power Factor, Energy |
| Metering | Per PDU (Billing Grade ±0.5%) |
| Metering per Outlet | No |
| Outlet Switching | No |
| Circuit Break Monitoring | No |
| Display | LCD Display (Current, Voltage, Power, kWh, IP Address), 90° / 180° / 270° Rotation |
| Network Interface | 1 × 10/100 Mbps Ethernet |
| Login Methods | Web, Telnet (Username & Password, 5 Permission Levels) |
| Supported Protocols | HTTP (TLS1.2), SNMP v1/v2c/v3, SNMP Trap, Modbus, DHCP, IPv4/IPv6, DNS, SMTP, TCP, SNTP, ARP, UDP, ICMP |
| Cascade | 2 × RS485 (Modbus, up to 11 devices including master) |
| Sensors | Supports 2 × Temperature & Humidity Sensors, External RS485 Device, 4 Digital Inputs, 2 Digital Outputs |
| Alarm Settings | Voltage, Current, Power, Temperature & Humidity Thresholds |
| Alarm Mode | Email, Sound & Light, Screen Flashing |
| Data Storage | Approx. 3 Months (Current, Voltage, Power, Energy) |
| Log List | Yes |
| MIB | Yes |
| API | Open API |
| USB Port | USB 2.0 Host (WiFi Module Supported) |
| Input Plug | IEC 60309 2P+E 32A (3 m Cable) |
| Input Cable | 3G6 mm² |
| Rated Current | 32 A |
| Rated Voltage | 250 VAC |
| Phase | Three Phase |
| Frequency | 50 / 60 Hz |
| Outlets | 24 × IEC C13 + 8 × IEC C19 |
| Circuit Breakers | 2 × 1P Hydraulic Magnetic Breaker (16A) |
| Dimensions | 1800 × 56 × 64 mm |
| Material | Aluminum Alloy |
| Color | Black |
| Mounting | Tool-Free or Universal Accessories |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5–95% RH (Non-condensing) |
| Max Elevation | 0 – 3000 m |
| Certification | ISO 9001 |
