- Rated Capacity: 8kVA (8000VA)
- Input Voltage Range: 90V–270V AC
- Output Voltage: 220V ±10%
- Frequency: 50/60Hz
- Response Time: <0.5s (for 10% input voltage change)
- Efficiency: ≥90%
- Protection Features: Overvoltage, Undervoltage, Overload, Short Circuit, Overheating
- Delay Function: Selectable long (255s) or short (5s) delay
- Display: Digital LED display showing input/output voltage and operational status
- Operating Temperature: -15°C to 45°C
- Humidity: <95% RH (non-condensing)
- Cooling Method: Natural air cooling
- Design: Wall-mounted, compact, and lightweight
- Applications: Suitable for computers, home appliances, medical equipment, and industrial automation
