iPower PC-TM 5kVA Automatic Voltage Regulator with 5 Relays, Digital Display, and Multi-Protection

 Description

The 5KVA Wall-Mounted Automatic Voltage Stabilizer (AVR) is a reliable voltage regulation solution designed to protect electrical and electronic equipment from voltage fluctuations. Featuring a 5000VA rated capacity, a wide 90V–270V AC input range, and a stable 220V ±10% output, it delivers efficient power regulation for residential, commercial, and industrial applications. Equipped with a digital LED display, multiple electrical protection features, and adjustable delay settings, it provides safe and reliable operation in a compact wall-mounted design.

Key Features

• 5KVA Power Capacity: Provides 5000VA rated capacity for compatible electrical appliances and equipment.
• Wide Input Voltage Range: Supports AC input voltages from 90V to 270V for reliable operation under varying power conditions.
• Stable Output Voltage: Delivers a nominal 220V AC output with ±10% voltage regulation tolerance.
• Dual Frequency Support: Compatible with 50Hz and 60Hz electrical power frequencies.
• Fast Response Time: Responds in less than 0.5 seconds to a 10% change in input voltage.
• High Efficiency: Provides an efficiency rating of 90% or higher for effective voltage regulation.
• Overvoltage Protection: Helps protect connected equipment against excessive voltage levels.
• Undervoltage Protection: Provides protection against excessively low voltage conditions.
• Overload Protection: Helps prevent damage caused by electrical loads exceeding rated capacity.
• Short Circuit Protection: Provides protection against electrical short circuits for improved safety.
• Overheating Protection: Helps protect the stabilizer from excessive operating temperatures.
• Adjustable Delay Function: Offers selectable long delay (255 seconds) and short delay (5 seconds) modes.
• Digital LED Display: Displays input voltage, output voltage, and operating status for convenient monitoring.
• Natural Air Cooling: Uses natural air circulation for efficient heat dissipation.
• Wall-Mounted Design: Compact and lightweight construction designed for convenient wall installation.
• Wide Operating Temperature: Supports temperatures ranging from -15°C to +45°C.
• Humidity Tolerance: Designed to operate in relative humidity below 95% without condensation.
• Home and Office Applications: Suitable for compatible computers, household appliances, and office equipment.
• Professional Applications: Suitable for compatible medical equipment, industrial automation systems, and commercial electrical installations.
