Grandstream GWN7660 Wi-Fi 6 Access Point, Dual-Band 2x2:2 MU-MIMO, 1.77Gbps, 500+ Clients, 175m Range, Dual Gigabit PoE
Low stock
Grandstream GWN7660 Wi-Fi 6 Access Point
Product Overview
The Grandstream GWN7660 is an enterprise-grade indoor Wi-Fi 6 access point designed for businesses, offices, commercial environments, and medium-to-high density wireless deployments. It delivers up to 1.77Gbps aggregate wireless throughput using dual-band 2x2:2 MU-MIMO with DL/UL OFDMA technology.
With support for more than 500 concurrent Wi-Fi clients, coverage of up to 175 meters, dual Gigabit Ethernet ports, PoE/PoE+ power, advanced QoS, Mesh networking, and centralized management options, the GWN7660 provides a scalable solution for modern business wireless networks.
Key Features
- Wi-Fi 6: Supports IEEE 802.11ax for efficient high-density wireless networking.
- 1.77Gbps Wireless Throughput: Up to 573.5Mbps on 2.4GHz and 1201Mbps on 5GHz.
- Dual-Band 2x2:2 MU-MIMO: Provides efficient simultaneous wireless communication with multiple devices.
- DL/UL OFDMA: Improves network efficiency in environments with many connected devices.
- 500+ Concurrent Clients: Designed for medium-to-high density wireless deployments.
- Up to 175m Coverage: Provides extended indoor wireless coverage depending on the deployment environment.
- Dual Gigabit Ethernet: Includes two auto-sensing 10/100/1000 Mbps Ethernet ports.
- PoE/PoE+: Supports IEEE 802.3af and 802.3at Power over Ethernet.
- 32 SSIDs: Supports up to 16 SSIDs per radio for network segmentation.
- Advanced QoS: Optimizes performance for voice, video, and other latency-sensitive applications.
- WPA3 Security: Supports modern wireless security standards and secure boot technology.
- Flexible Management: Supports embedded controller, GDMS Networking, and GWN Manager.
Technical Specifications
| Item | Specification |
|---|---|
| Brand | Grandstream |
| Model | GWN7660 |
| Product Type | Indoor Wi-Fi 6 Access Point |
| Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Wireless Bands | 2.4GHz & 5GHz Dual-Band |
| MIMO | Dual-Band 2x2:2 MU-MIMO |
| Wireless Technology | DL/UL OFDMA |
| Maximum Aggregate Throughput | 1.77Gbps |
| 2.4GHz Throughput | Up to 573.5Mbps |
| 5GHz Throughput | Up to 1201Mbps |
| Concurrent Clients | 500+ |
| Coverage Range | Up to 175m (575 ft) |
| Network Interfaces | 2 × 10/100/1000 Mbps Gigabit Ethernet Ports |
| Antennas | 2 × Dual-Band Internal Antennas |
| Antenna Gain | 2.4GHz: 3dBi / 5GHz: 4dBi |
| SSIDs | 32 Total, 16 per Radio |
| Channel Width | 2.4GHz: 20/40MHz; 5GHz: 20/40/80MHz |
| Security | WEP, WPA/WPA2-PSK, WPA/WPA2-Enterprise, WPA3 |
| Power | PoE 802.3af / PoE+ 802.3at |
| Maximum Power Consumption | 9W |
| Management | Embedded Controller, GDMS Networking & GWN Manager |
| Embedded Controller Capacity | Up to 50 Local GWN Access Points |
| Mounting | Indoor Wall or Ceiling Mount |
| Dimensions | 180.4 × 180.4 × 40.8mm |
| Weight | 443g |
| Operating Temperature | 0°C to 45°C |
Applications
- Business and corporate offices
- Hotels and hospitality environments
- Schools and educational facilities
- Retail stores and shopping centers
- Voice-over-Wi-Fi deployments
- Medium-to-high density wireless networks
- Commercial buildings and multi-floor environments
