- Form Factor: M.2 2280; Interface: PCI‑Express 5.0 x4, NVMe 2.0
- Capacity: 2 TB (1984 GiB useable)
- Controller: Phison PS5026‑E26 (12 nm, 8 NAND channels with 64CES)
- NAND Flash: 232‑layer 3D TLC
- Sequential Read: up to 14,500 MB/s; Write: up to 12,700 MB/s (internal testing) :contentReference[oaicite:1]{index=1}
- DRAM Cache: 4 GB LPDDR4 (2 TB model) :contentReference[oaicite:2]{index=2}
- MTBF: 1.6 million hours; TBW: ~1,400 TB :contentReference[oaicite:3]{index=3}
- Operating Temp: 0–70 °C; Storage: –40–85 °C
- Dimensions: 80 × 22 × 2.3 mm; Power active: ~11.5 W; Power idle: <144 mW (PS3) / <85 mW (PS4) :contentReference[oaicite:4]{index=4}
- Requires motherboard heatsink for optimal performance :contentReference[oaicite:5]{index=5}
- Software support via GIGABYTE Control Center (GCC)
- Warranty: 5 years limited :contentReference[oaicite:6]{index=6}
