CMX PMX620 Professional 6-Channel Powered Audio Mixer, 2×200W Amplifier, 24-Bit DSP Effects, 7-Band EQ, USB/SD MP3 Player

Description

The CMX PMX620 is a professional 6-channel powered audio mixing console designed for live performances, conferences, meeting rooms, and public address systems. Featuring a built-in stereo power amplifier delivering 2 × 200W at 4Ω or 2 × 125W at 8Ω, it combines audio mixing, amplification, and digital signal processing in one convenient unit. With a 24-bit DSP effects processor, 7-band graphic equalizer, and USB/SD MP3 playback, it provides flexible sound control for professional audio installations.

Key Features

• Brand: CMX.
• Model: PMX620.
• Product Type: Professional Powered Audio Mixing Console.
• Mixing Channels: 6 channels.
• Built-in Amplifier: Stereo power amplifier.
• Rated Power Output: 2 × 200W at 4Ω or 2 × 125W at 8Ω.
• Audio Inputs: Supports microphone, line-level, and tape audio sources.
• DSP Effects: 24-bit digital signal processor with 48kHz sampling.
• Graphic Equalizer: Built-in 7-band EQ for sound adjustment.
• Media Playback: Integrated MP3 player with USB and SD card inputs.
• Audio Control: Independent left and right channel output control.
• Frequency Response: 20Hz–20kHz.
• Signal-to-Noise Ratio: Greater than 85dB.
• Total Harmonic Distortion: Less than 0.03% at rated power.
• Crosstalk: -82dB.
• Microphone Input Sensitivity: -60dB.
• Line Input Sensitivity: -20dB.
• Power Supply: AC 110V or 230V, 50/60Hz.
• Applications: Live sound reinforcement, conferences, meeting rooms, hotels, mosques, churches, and public address systems.
