Product Description
The CSK-512HT is a high-performance 5.25” 2-way ceiling speaker featuring a 100V transformer and slim-line design, tailored for commercial audio, public address, and PA systems. Engineered with a hi-flex polypropylene cone and integrated 1” tweeter, it delivers extended low frequencies and crisp highs. Its frameless magnetic grille ensures a sleek finish and effortless installation.
- Professional 5.25” 2-way coaxial ceiling speaker
- Built-in 100V transformer with 20W/10W/5W power taps
- Hi-flex polypropylene cone for deep bass performance
- 1” tweeter for detailed high-frequency response
- Frameless magnetic grille with ABS baffle for modern aesthetics
- Flush-mount installation with secure spring clips
- Ideal for PA systems, commercial audio, offices, hotels, and more
Specifications
-
Model: CSK-512HT
-
Description: 5.25” 2-Way Ceiling Speaker
-
Power (RMS) 100V: 20W
-
Power Taps: 20W / 10W / 5W @ 100V
-
Sensitivity (1W/1m): 89dB
-
Max SPL: 101dB
-
Frequency Response: 80Hz–20kHz
-
Speaker Driver: 5.25" bass + 1" tweeter (2-way system)
-
Finish: ABS baffle (black), Magnetic steel grille (white)
-
Cutout Size: Ø180mm
-
Dimensions: Ø205 × 90mm
-
Weight: 1.3kg
