Build Volume: 256 × 256 × 256 mm
-
Chassis: Steel frame with aluminum & glass shell
-
Toolhead: All‑metal hotend, hardened steel extruder gears, 0.4 mm nozzle (optional 0.2/0.6/0.8 mm)
-
Max Hotend Temp: 300 °C
-
Filament: 1.75 mm, includes cutter
-
Build Plate: Flexible steel plate; textured PEI or Cool Plate; max bed temp 110 °C (220 V) / 120 °C (110 V)
-
Max Print Speed: 500 mm/s; Acceleration: 20 m/s²
-
Cooling: Closed‑loop fans for part, hotend, chamber & electronics
-
Bed Leveling: Dual auto‑bed leveling via LIDAR & force sensor + AI‑inspected first layer & spaghetti detection
-
Camera: 1080p chamber monitoring; supports timelapse & print resume
-
Air Filter: Activated carbon VOC filter
-
Display: 5″ 1280×720 touch screen; Connectivity: Wi‑Fi, Bambu‑Bus, micro‑SD
-
Electronics: Dual‑core Cortex M4 + Quad ARM A7 1.2 GHz + NPU (2 TOPS)
-
Dimensions: 389 × 389 × 457 mm; Net Weight: 14.13 kg; Package: 480 × 480 × 590 mm; Gross Weight w/ AMS: 22.3 kg
-
Power: 100–240 VAC, 50/60 Hz; Max 1,000 W @220 V / 350 W @110 V
-
Filament Support: PLA, PETG, TPU, PVA, PET, PLA‑CF/PA‑CF, ABS, ASA, PA, PC; ideal for carbon/glass fiber & engineering materials
-
Software: 3MF support, Bambu Studio + mobile control via Bambu Handy
