- Display: 54.64″ LCD panel, ELED backlight
- Resolution: 3840 × 2160 (4K UHD)
- Brightness: 350 cd/m² (min.), 400 cd/m² (typ.)
- Contrast Ratio: 1200:1 (typ.)
- Response Time: 8 ms (typ.)
- Color Depth: 1.07B (8-bit + FRC), 85% NTSC color gamut
- Viewing Angle: 178° (H/V)
- Glass: 2.7 mm AG+AF tempered glass
- Touch Technology: Infrared touch, up to 40 points, ≤5 ms response
- Touch Accuracy: ±1 mm across 90% of active area
- Chipset: Rockchip RK3588 (Quad Cortex-A76 + Quad Cortex-A55, up to 2.4 GHz)
- GPU: Mali-G610
- Memory: 8 GB
- Storage: 128 GB
- Operating System: Android 13.0
- Audio: 2 × 10 W speakers (6 Ω)
- Microphones: Built-in 8-mic array
- Camera: Plug-in USB Type-C camera (removable)
- Connectivity:
- HDMI In ×1 (3840×2160@60Hz, HDMI 2.1 with ARC)
- HDMI Out ×1 (loop out, 4K@60Hz)
- USB Type-C In ×1 (4K@60Hz, DRP, PD 15 W)
- USB 3.0 Type-A ×2 (media playback, one with “follow” function)
- USB 3.0 Type-B ×1 (Touch for HDMI)
- LAN: RJ-45, 10/100/1000 Mbps
- SPDIF Optical Out ×1
- RS232 In ×1
- Wireless: Wi-Fi 5 (RTL8822) or Wi-Fi 6 (AP6275P), Bluetooth 5.3
- Power Supply: AC 100–240 V, 50/60 Hz
- Power Consumption: Max 190 W; Standby <0.5 W
- Dimensions (W×D×H): 1259.3 × 72.5 × 730.2 mm
- Packaging Size: 1465 × 190 × 870 mm
- Weight: (Refer to product label; size only in spec)
- Housing: Aluminum + plastic, white
- Mounting: VESA 400 × 400 mm (M8 screws)
- Accessories: 2× Touch Pens, Power Cord, HDMI Cable, USB A-B Cable, Remote Control, Stand Base, Adapter, Warranty Card, Certificate (Battery optional)
- Environmental: 0–40 °C operating, –10–60 °C storage; 20–80% RH (non-condensing); altitude ≤5000 m
