Sumitomo Electric FC-6 Series High Precision Fiber Cleavers
The trusted solution for clean, consistent fiber cleaves.
The Sumitomo Electric FC-6 Series offers professional-grade fiber cleaving for both single fibers and 12-fiber ribbons. Designed for precision, long life, and easy operation, the FC-6 cleavers feature selectable blade operation — allowing users to choose between automatic blade rotation or a fixed blade position to best suit their workflow.
Built using Sumitomo's high-quality hard metal technology, the FC-6 Series cleavers consistently deliver up to 54,000 cleaves per blade without requiring adjustment. The large integrated offcut collector safely stores fiber shards, ensuring a clean and safe work environment. Genuine Sumitomo Electric cleaver blades, identifiable by a security hologram, ensure reliable performance and product authenticity.
Key Features
- High precision bench-top cleaver for single fibers and ribbon fibers (up to 12 fibers)
- Selectable blade operation: automatic rotation or fixed blade mode
- High quality Sumitomo Electric blade for consistent performance over 54,000 cleaves
- Large fiber offcut bin for safe and easy disposal of fiber shards
- One-action cleave for smooth, efficient operation
- Designed and manufactured in Japan
Specifications
- Applicable fibers: Single fiber and ribbon fiber (up to 12 fibers)
- Material: Silica glass
- Cladding diameter: Φ125 μm
- Cleave angle (typical): 0.5 degrees (single fiber)
- Cleave length:
- Single fiber: 5–20 mm (Φ0.25 mm coating), 10–20 mm (Φ0.9 mm coating)
- Ribbon fiber: 10 mm
- Blade life: Up to 54,000 fibers (2,250 cleaves × 24 blade positions)
- Dimensions: 100(W) × 81(D) × 63(H) mm or 63(W) × 77(D) × 63(H) mm depending on model
- Weight: Approx. 380g–420g depending on model
Included Parts
- FC-6 Series Main Body
- Carrying Case (AP-FC6M)
- Single Fiber Adapter (AP-FC6M)
- Offcut Collector (CU-FC6)
- Replacement Blade (FCP-20BL)
- Cleaning Brush
- Hexagonal Wrench
- Strap
Important Note
Always use genuine Sumitomo Electric replacement blades and accessories, identifiable by the security hologram. Non-genuine parts may affect cleaver performance and void warranties.
Experience reliable, high-precision fiber preparation with the FC-6 Series — engineered for professionals who demand the best.
