Frequency Bands: 136–174 MHz, 403–470 MHz, 450–527 MHz, 300–360 MHz, 350–400 MHz
-
RF Output Power: 1–50 W
-
Channel Capacity: 64 channels
-
Operating Voltage (AC): 100–240 V AC, 47–63 Hz
-
Operating Voltage (DC): 11.0–14.4 V DC
-
Operating Temperature Range: -30°C to +60°C
-
Humidity: 90% relative humidity, non-condensing
-
Dimensions: 44 mm (H) x 483 mm (W) x 370 mm (D)
-
Weight: 8.6 kg
-
Power Consumption (Standby): 0.25 A (110 V AC), 0.18 A (240 V AC)
-
Power Consumption (Transmitting): 1.5 A (110 V AC), 0.9 A (240 V AC)
-
Integrated Battery Charger: 3A battery charger included
-
USB Port: Front panel USB port for easy configuration
-
Remote Management: Optional support for remote management
-
Expansion Modules: Provision for future expansion modules
-
Compliance: CE, RoHS, and WEEE compliant
