AVer CAM520 Pro3 – Enterprise-Grade PTZ Camera for Hybrid Conferencing
The AVer CAM520 Pro3 is a powerful PTZ conferencing camera designed for mid-to-large meeting rooms. With a total 36X zoom, Smart Composition, HDMI/USB/IP outputs, and enhanced SmartFrame technology, it offers a seamless and professional video experience across platforms like Zoom, Microsoft Teams, and Google Meet.
-
36X Total Zoom: 12X optical + 24X lossless digital zoom for capturing crystal-clear details at any distance.
-
Smart Composition: Built-in AI framing automatically captures individual participants’ faces or half-body shots—no software required.
-
SmartFrame Technology: AI-powered auto-framing focuses on participants up to 7 meters away, even with masks on.
-
Preset Framing: Automatically follows presenters through defined zones for hands-free tracking.
-
Enterprise-Grade Imaging: Sony low-light 8MP sensor with WDR for sharp, well-balanced video in any lighting.
-
Flexible Connectivity: Simultaneous output via USB 3.1, HDMI, and IP streaming (RTSP/RTMP H.264).
-
Advanced Control: Remote control, VISCA over IP, RS232, Web UI, and AVer PTZApp 2 software compatibility.
-
PoE+ Support: Simplified power and connectivity through a single Ethernet cable.
Technical Specifications:
-
Sensor: Sony 8MP CMOS | Resolution: Full HD 1080p @ 60fps
-
Zoom: 12X Optical, 36X Total (via PTZApp 2)
-
FOV: 80.5° D / 72.8° H / 44.1° V
-
Pan/Tilt: ±170° / +90° to -30° | Presets: 10 via remote, 128 via VISCA
-
Outputs: USB 3.1, HDMI, IP (RJ45, PoE+)
-
Video Format: YUV, YUY2, MJPEG | Streaming: H.264 via RTSP/RTMP
-
Dimensions: 182 x 142.7 x 153 mm | Weight: 1.47 kg
-
Control: IR Remote, VISCA, PTZApp 2, Web UI (Chrome only)
-
System Compatibility: Windows®, macOS®, Google Chromebox, UVC Plug-and-Play
Package Includes: CAM520 Pro3, Remote Control, USB & HDMI Cables, Power Adapter, Wall Mount, Ceiling Mount, RS232 Adapters, Tripod Screw
